[!NOTE] Work in progress

with help of GenAI (gemini 2.5 pro)

Kubelet Client Certificate Rotation Analysis

Customers frequently inquire about the kubelet-client-current.pem file, its rotation process, and timing. This document analyzes these aspects.

Here is a schematic diagram of the conclusion of this article.

problem statement

For a new installed cluster, we can check the kubelet-client-*.pem file and the expiration time.


        # select a master node

        MASTER_NODE=$(oc get nodes -l node-role.kubernetes.io/master -o jsonpath='{.items[0].metadata.name}')

        # list the pem files

        oc debug node/${MASTER_NODE} -- chroot /host find /var/lib/kubelet/pki/ -name 'kubelet-client*.pem'

        # /var/lib/kubelet/pki/kubelet-client-2025-07-08-22-39-29.pem

        # /var/lib/kubelet/pki/kubelet-client-2025-07-10-07-31-58.pem

        # /var/lib/kubelet/pki/kubelet-client-current.pem

        # list all expiration date

        oc debug node/${MASTER_NODE} -- chroot /host find /var/lib/kubelet/pki/ -name 'kubelet-client*.pem' -exec  openssl x509 -in {} -noout -dates \;

        # notBefore=Jul  8 22:34:29 2025 GMT

        # notAfter=Jul  9 22:29:59 2025 GMT

        # notBefore=Jul 10 07:26:58 2025 GMT

        # notAfter=Aug  9 07:26:58 2025 GMT

        # notBefore=Jul 10 07:26:58 2025 GMT

        # notAfter=Aug  9 07:26:58 2025 GMT

As observed, the first certificate file has a 1-day expiration, while the subsequent one is valid for almost 30 days.

However, in clusters that have been running for an extended period, the expiration dates of these certificate files can appear inconsistent. Below is an example list of kubelet-client*.pem expiration dates:

1 days
30 days
24 days
22 days
22 days
21 days

In the following sections, we will explain why these certificate expiration dates can vary.

chain of certification

The kubelet-client-current.pem file is part of a certificate chain. We can use openssl to inspect and verify this chain. The following commands demonstrate how to identify and verify the certificates within the chain.


        # get the root CA

        oc get secret csr-signer-signer -n openshift-kube-controller-manager-operator -o jsonpath='{.data.tls\.crt}' | base64 --decode > root-for-csr-signer.crt

        # get the intermediate CA

        oc get secret csr-signer -n openshift-kube-controller-manager -o jsonpath='{.data.tls\.crt}' | base64 --decode > intermediate-ca.crt

        # get the leaf CA (kubelet-client pem)

        WORKER_NODE=$(oc get nodes -l node-role.kubernetes.io/worker -o jsonpath='{.items[0].metadata.name}')
        oc debug node/${WORKER_NODE} -- chroot /host cat /var/lib/kubelet/pki/kubelet-client-current.pem > kubelet-client.pem

        # verify the chain

        openssl verify -CAfile root-for-csr-signer.crt -untrusted intermediate-ca.crt kubelet-client.pem

        # kubelet-client.pem: OK


        # print root-for-csr-signer.crt intermediate-ca.crt kubelet-client.pem's issuer, subject, date

        echo "--- root-for-csr-signer.crt ---"
        openssl x509 -in root-for-csr-signer.crt -noout -issuer -subject -dates

        # issuer=CN = openshift-kube-controller-manager-operator_csr-signer-signer@1752132658

        # subject=CN = openshift-kube-controller-manager-operator_csr-signer-signer@1752132658

        # notBefore=Jul 10 07:30:57 2025 GMT

        # notAfter=Sep  8 07:30:58 2025 GMT

        echo "--- intermediate-ca.crt ---"
        openssl x509 -in intermediate-ca.crt -noout -issuer -subject -dates

        # issuer=CN = openshift-kube-controller-manager-operator_csr-signer-signer@1752132658

        # subject=CN = kube-csr-signer_@1752132658

        # notBefore=Jul 10 07:30:57 2025 GMT

        # notAfter=Aug  9 07:30:58 2025 GMT

        echo "--- kubelet-client.pem ---"
        openssl x509 -in kubelet-client.pem -noout -issuer -subject -dates

        # issuer=CN = kube-csr-signer_@1752132658

        # subject=O = system:nodes, CN = system:node:control-plane-cluster-fp5zr-1-1

        # notBefore=Jul 10 07:26:58 2025 GMT

        # notAfter=Aug  9 07:26:58 2025 GMT

rotation logic

For the root ca csr-signer-signer, here is the core logic, source code is here:

        certrotation.RotatedSigningCASecret{
                    Namespace: operatorclient.OperatorNamespace,
                    // this is not a typo, this is the signer of the signer
                    Name: "csr-signer-signer",
                    AdditionalAnnotations: certrotation.AdditionalAnnotations{
                        JiraComponent: "kube-controller-manager",
                    },
                    Validity:               60 * rotationDay,
                    Refresh:                30 * rotationDay,
                    RefreshOnlyWhenExpired: refreshOnlyWhenExpired,
                    Informer:               kubeInformersForNamespaces.InformersFor(operatorclient.OperatorNamespace).Core().V1().Secrets(),
                    Lister:                 kubeInformersForNamespaces.InformersFor(operatorclient.OperatorNamespace).Core().V1().Secrets().Lister(),
                    Client:                 secretsGetter,
                    EventRecorder:          eventRecorder,
                    UseSecretUpdateOnly:    true,
                },

We can see it has 60 days for validity and 30 days for refresh.

For the intermediate CA csr-signer, the core logic is defined here:

        certrotation.RotatedSelfSignedCertKeySecret{
                    Namespace: operatorclient.OperatorNamespace,
                    Name:      "csr-signer",
                    AdditionalAnnotations: certrotation.AdditionalAnnotations{
                        JiraComponent: "kube-controller-manager",
                    },
                    Validity:               30 * rotationDay,
                    Refresh:                15 * rotationDay,
                    RefreshOnlyWhenExpired: refreshOnlyWhenExpired,
                    CertCreator: &certrotation.SignerRotation{
                        SignerName: "kube-csr-signer",
                    },

We can see it has 30 days validity and 15 days refresh interval.

For the leaf certificate kubelet-client.pem, the situation is more complex. The initial logic determines the requested duration, as shown in the source code:

  cluster-signing-duration:
          - "720h"

We can verify this parameter by running the following command:

MASTER_NODE=$(oc get nodes -l node-role.kubernetes.io/master -o jsonpath='{.items[0].metadata.name}')

        oc debug node/${MASTER_NODE} -- chroot /host grep 'cluster-signing-duration' /etc/kubernetes/manifests/kube-controller-manager-pod.yaml

        oc debug node/${MASTER_NODE} -- chroot /host cat  /etc/kubernetes/manifests/kube-controller-manager-pod.yaml | jq . | grep cluster-signing-duration

        # ............. --cluster-signing-duration=720h ...................

As shown, when rotating a new kubelet-client.pem, kube-controller-manager attempts to allocate a 720 hour (30-day) period.

Another key aspect is timing. The Kubelet’s internal logic triggers certificate rotation when the current kubelet-client.pem reaches 70-90% of its 30-day lifetime. This rotation is randomized to prevent all nodes from simultaneously burdening the Kube-API server in large clusters. The relevant source code is located here:

// nextRotationDeadline returns a value for the threshold at which the
        // current certificate should be rotated, 80%+/-10% of the expiration of the
        // certificate.
        func (m *manager) nextRotationDeadline() time.Time {
            // forceRotation is not protected by locks
            if m.forceRotation {
                m.forceRotation = false
                return m.now()
            }

            m.certAccessLock.RLock()
            defer m.certAccessLock.RUnlock()

            if !m.certSatisfiesTemplateLocked() {
                return m.now()
            }

            notAfter := m.cert.Leaf.NotAfter
            totalDuration := float64(notAfter.Sub(m.cert.Leaf.NotBefore))
            deadline := m.cert.Leaf.NotBefore.Add(jitteryDuration(totalDuration))

            m.logf("%s: Certificate expiration is %v, rotation deadline is %v", m.name, notAfter, deadline)
            return deadline
        }

        // jitteryDuration uses some jitter to set the rotation threshold so each node
        // will rotate at approximately 70-90% of the total lifetime of the
        // certificate.  With jitter, if a number of nodes are added to a cluster at
        // approximately the same time (such as cluster creation time), they won't all
        // try to rotate certificates at the same time for the rest of the life of the
        // cluster.
        //
        // This function is represented as a variable to allow replacement during testing.
        var jitteryDuration = func(totalDuration float64) time.Duration {
            return wait.Jitter(time.Duration(totalDuration), 0.2) - time.Duration(totalDuration*0.3)
        }

summary everything up

The intermediate CA has a 30-day lifetime and refreshes every 15 days. When Kubelet requests rotation of kubelet-client.pem at 70-90% of its 30-day lifetime, the intermediate CA may not have sufficient remaining validity to issue a new kubelet-client.pem for the full 30-day period. In such cases, it will issue a certificate valid only until the intermediate CA’s own notAfter time.

kubelet server pem

kueblet-server.pem use the same logic as kubelet-client.pem.

oc debug node/${MASTER_NODE} -- chroot /host find /var/lib/kubelet/pki/ -name 'kubelet-server*.pem'

        # /var/lib/kubelet/pki/kubelet-server-2025-07-08-22-39-41.pem

        # /var/lib/kubelet/pki/kubelet-server-2025-07-10-07-33-02.pem

        # /var/lib/kubelet/pki/kubelet-server-current.pem

        oc debug node/${MASTER_NODE} -- chroot /host find /var/lib/kubelet/pki/ -name 'kubelet-server*.pem' -exec  openssl x509 -in {} -noout -dates \;

        # notBefore=Jul  8 22:34:41 2025 GMT

        # notAfter=Jul  9 22:29:59 2025 GMT

        # notBefore=Jul 10 07:28:02 2025 GMT

        # notAfter=Aug  9 07:28:02 2025 GMT

        # notBefore=Jul 10 07:28:02 2025 GMT

        # notAfter=Aug  9 07:28:02 2025 GMT


        # get the root CA

        oc get secret csr-signer-signer -n openshift-kube-controller-manager-operator -o jsonpath='{.data.tls\.crt}' | base64 --decode > root-for-csr-signer.crt

        # get the intermediate CA

        oc get secret csr-signer -n openshift-kube-controller-manager -o jsonpath='{.data.tls\.crt}' | base64 --decode > intermediate-ca.crt

        # get the leaf CA (kubelet-client pem)

        WORKER_NODE=$(oc get nodes -l node-role.kubernetes.io/worker -o jsonpath='{.items[0].metadata.name}')
        oc debug node/${WORKER_NODE} -- chroot /host cat /var/lib/kubelet/pki/kubelet-server-current.pem > kubelet-server.pem

        # verify the chain

        openssl verify -CAfile root-for-csr-signer.crt -untrusted intermediate-ca.crt kubelet-server.pem

        # kubelet-server.pem: OK


        # print root-for-csr-signer.crt intermediate-ca.crt kubelet-client.pem's issuer, subject, date

        echo "--- root-for-csr-signer.crt ---"
        openssl x509 -in root-for-csr-signer.crt -noout -issuer -subject -dates

        # issuer=CN = openshift-kube-controller-manager-operator_csr-signer-signer@1752132658

        # subject=CN = openshift-kube-controller-manager-operator_csr-signer-signer@1752132658

        # notBefore=Jul 10 07:30:57 2025 GMT

        # notAfter=Sep  8 07:30:58 2025 GMT

        echo "--- intermediate-ca.crt ---"
        openssl x509 -in intermediate-ca.crt -noout -issuer -subject -dates

        # issuer=CN = openshift-kube-controller-manager-operator_csr-signer-signer@1752132658

        # subject=CN = kube-csr-signer_@1752132658

        # notBefore=Jul 10 07:30:57 2025 GMT

        # notAfter=Aug  9 07:30:58 2025 GMT

        echo "--- kubelet-server.pem ---"
        openssl x509 -in kubelet-server.pem -noout -issuer -subject -dates

        # issuer=CN = kube-csr-signer_@1752132658

        # subject=O = system:nodes, CN = system:node:control-plane-cluster-fp5zr-1-1

        # notBefore=Jul 10 07:28:02 2025 GMT

        # notAfter=Aug  9 07:28:02 2025 GMT
