[!NOTE] Work in progress

with the help of Gemini pro 2.5

cert analyze for node-system-admin-client

For the fresh installed ocp cluster:

For the existing ocp cluster:

Customer checks the internal certs node-system-admin-client, this cert is used for user system:admin, which has cluster-admin role.

As we can see from the below output, the cert will expire in one year.

oc get secret -n openshift-kube-apiserver-operator node-system-admin-client -o jsonpath='{.data.tls\.crt}' | base64 --decode | openssl x509 -noout -issuer -subject -dates

        # issuer=CN=openshift-kube-apiserver-operator_node-system-admin-signer@1752634724

        # subject=O=system:masters, CN=system:admin

        # notBefore=Jul 16 02:58:51 2025 GMT

        # notAfter=Jul 16 02:58:44 2026 GMT


        oc get secret -n openshift-kube-apiserver-operator node-system-admin-signer -o jsonpath='{.data.tls\.crt}' | base64 --decode | openssl x509 -noout -issuer -subject -dates

        # issuer=CN=openshift-kube-apiserver-operator_node-system-admin-signer@1752634724

        # subject=CN=openshift-kube-apiserver-operator_node-system-admin-signer@1752634724

        # notBefore=Jul 16 02:58:43 2025 GMT

        # notAfter=Jul 16 02:58:44 2026 GMT

        # verify the certification chain

        oc get secret -n openshift-kube-apiserver-operator node-system-admin-client -o jsonpath='{.data.tls\.crt}' | base64 --decode > client.crt

        oc get secret -n openshift-kube-apiserver-operator node-system-admin-signer -o jsonpath='{.data.tls\.crt}' | base64 --decode > root-for-csr-signer.crt

        openssl verify -CAfile root-for-csr-signer.crt client.crt

        # client.crt: OK

But based on the source code, it should have 2 years of validity. Let’s check the source code.

        certrotation.RotatedSelfSignedCertKeySecret{
                    Namespace: operatorclient.OperatorNamespace,
                    Name:      "node-system-admin-client",
                    AdditionalAnnotations: certrotation.AdditionalAnnotations{
                        JiraComponent: "kube-apiserver",
                    },
                    // This needs to live longer then control plane certs so there is high chance that if a cluster breaks
                    // because of expired certs these are still valid to use for collecting data using localhost-recovery
                    // endpoint with long lived serving certs for localhost.
                    Validity: 2 * 365 * defaultRotationDay,
                    // We rotate sooner so certs are always valid for 90 days (30 days more then kube-control-plane-signer)
                    Refresh:                30 * defaultRotationDay,
                    RefreshOnlyWhenExpired: refreshOnlyWhenExpired,
                    CertCreator: &certrotation.ClientRotation{
                        UserInfo: &user.DefaultInfo{
                            Name:   "system:admin",
                            Groups: []string{"system:masters"},
                        },
                    },
                    Informer:      kubeInformersForNamespaces.InformersFor(operatorclient.OperatorNamespace).Core().V1().Secrets(),
                    Lister:        kubeInformersForNamespaces.InformersFor(operatorclient.OperatorNamespace).Core().V1().Secrets().Lister(),
                    Client:        kubeClient.CoreV1(),
                    EventRecorder: eventRecorder,

                    // we will remove this when we migrate all of the affected secret
                    // objects to their intended type: https://issues.redhat.com/browse/API-1800
                    UseSecretUpdateOnly: true,
                },

The answer is clear, the root CA (signer) has 1 year expiration time. So the issued cert node-system-admin-client can not be longer than that.

And the root CA (signer) has 1 year expiration time, and will be refreshed at 80% of lifetime. Here are source code.

        certrotation.RotatedSigningCASecret{
                    Namespace: operatorclient.OperatorNamespace,
                    Name:      "node-system-admin-signer",
                    AdditionalAnnotations: certrotation.AdditionalAnnotations{
                        JiraComponent: "kube-apiserver",
                    },
                    Validity: 1 * 365 * defaultRotationDay,
                    // Refresh set to 80% of the validity.
                    // This range is consistent with most other signers defined in this pkg.
                    Refresh:                292 * defaultRotationDay,
                    RefreshOnlyWhenExpired: refreshOnlyWhenExpired,
                    Informer:               kubeInformersForNamespaces.InformersFor(operatorclient.OperatorNamespace).Core().V1().Secrets(),
                    Lister:                 kubeInformersForNamespaces.InformersFor(operatorclient.OperatorNamespace).Core().V1().Secrets().Lister(),
                    Client:                 kubeClient.CoreV1(),
                    EventRecorder:          eventRecorder,

                    // we will remove this when we migrate all of the affected secret
                    // objects to their intended type: https://issues.redhat.com/browse/API-1800
                    UseSecretUpdateOnly: true,
                },

simulate rotation

We will simualte the key/cert rotation, we can see after delete the signer, the client cert does not autorenew. But the cert chain failed. Do not worry about the failed, the real rotation process will care about the cert chain, and will store the old cert public key into CA bundle, to avoid the cert chain failure.

Get Signer CA Details:


        # Get creation timestamp

        oc get secret node-system-admin-signer -n openshift-kube-apiserver-operator -o=jsonpath='{.metadata.creationTimestamp}{"\n"}'

        # 2025-07-08T22:40:46Z

        # Get serial number and subject

        oc get secret node-system-admin-signer -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d | openssl x509 -noout -serial -issuer -subject -dates

        # serial=038106BD877BDCBE

        # issuer=CN = openshift-kube-apiserver-operator_node-system-admin-signer@1752014437

        # subject=CN = openshift-kube-apiserver-operator_node-system-admin-signer@1752014437

        # notBefore=Jul  8 22:40:37 2025 GMT

        # notAfter=Jul  8 22:40:38 2026 GMT

Get Leaf Certificate Details:


        # Get creation timestamp

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.metadata.creationTimestamp}{"\n"}'

        # 2025-07-08T22:40:53Z

        # Get serial number and issuer

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d | openssl x509 -noout -serial -issuer -subject -dates

        # serial=023EE1F3311AF1D5

        # issuer=CN = openshift-kube-apiserver-operator_node-system-admin-signer@1752014437

        # subject=O = system:masters, CN = system:admin

        # notBefore=Jul  8 22:40:50 2025 GMT

        # notAfter=Jul  8 22:40:38 2026 GMT

Manually Rotate the Signer CA

oc delete secret node-system-admin-signer -n openshift-kube-apiserver-operator

Get Signer CA Details: (IT IS UPDATED)


        # Get creation timestamp

        oc get secret node-system-admin-signer -n openshift-kube-apiserver-operator -o=jsonpath='{.metadata.creationTimestamp}{"\n"}'

        # 2025-07-17T06:30:49Z

        # Get serial number and subject

        oc get secret node-system-admin-signer -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d | openssl x509 -noout -serial -issuer -subject -dates

        # serial=31A8CCE1005C0642

        # issuer=CN = openshift-kube-apiserver-operator_node-system-admin-signer@1752733849

        # subject=CN = openshift-kube-apiserver-operator_node-system-admin-signer@1752733849

        # notBefore=Jul 17 06:30:48 2025 GMT

        # notAfter=Jul 17 06:30:49 2026 GMT

Get Leaf Certificate Details: (IT IS NOT UPDATED).


        # Get creation timestamp

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.metadata.creationTimestamp}{"\n"}'

        # 2025-07-08T22:40:53Z

        # Get serial number and issuer

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d | openssl x509 -noout -serial -issuer -subject -dates

        # serial=023EE1F3311AF1D5

        # issuer=CN = openshift-kube-apiserver-operator_node-system-admin-signer@1752014437

        # subject=O = system:masters, CN = system:admin

        # notBefore=Jul  8 22:40:50 2025 GMT

        # notAfter=Jul  8 22:40:38 2026 GMT

State Verification


        # Extract the new CA certificate

        oc get secret node-system-admin-signer -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d > new-ca.crt

        # Extract the new leaf certificate

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d > new-leaf.crt

        # Verify the chain

        openssl verify -CAfile new-ca.crt new-leaf.crt

        # O = system:masters, CN = system:admin

        # error 20 at 0 depth lookup: unable to get local issuer certificate

        # error new-leaf.crt: verification failed

Forcing the Leaf Certificate Update

oc patch secret node-system-admin-client -n openshift-kube-apiserver-operator -p='{"metadata": {"annotations": {"auth.openshift.io/certificate-not-after": null}}}'

        # Get creation timestamp

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.metadata.creationTimestamp}{"\n"}'

        # 2025-07-08T22:40:53Z

        # Get serial number and issuer

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d | openssl x509 -noout -serial -issuer -subject -dates

        # serial=028AC59829CF3F15

        # issuer=CN = openshift-kube-apiserver-operator_node-system-admin-signer@1752733849

        # subject=O = system:masters, CN = system:admin

        # notBefore=Jul 17 06:52:17 2025 GMT

        # notAfter=Jul 17 06:30:49 2026 GMT

        oc get secret node-system-admin-signer -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d > new-ca.crt

        # Extract the new leaf certificate

        oc get secret node-system-admin-client -n openshift-kube-apiserver-operator -o=jsonpath='{.data.tls\.crt}' | base64 -d > new-leaf.crt

        # Verify the chain

        openssl verify -CAfile new-ca.crt new-leaf.crt

        # new-leaf.crt: OK

end
