RHEL/centos 8 build kernel

本文描述如何在rhel8上编译自定义的内核。

业务背景是,客户需要使用mellanox网卡高级功能,需要kernel打开相应的选项,才可以使用,所以我们就编译一个新的内核出来。

讲解视频

实验步骤


        # https://access.redhat.com/articles/3938081

        # grubby --info=ALL | grep title

        # https://blog.packagecloud.io/eng/2015/04/20/working-with-source-rpms/

        export PROXY="192.168.253.1:5085"
        export PROXY="192.168.203.1:5085"

        # 由于需要rhel8.3,而当前8.3还是beta状态,我们需要注册特殊的订阅。

        subscription-manager --proxy=$PROXY register --username **** --password ********

        # subscription-manager config --rhsm.baseurl=https://china.cdn.redhat.com

        # subscription-manager config --rhsm.baseurl=https://cdn.redhat.com

        subscription-manager --proxy=$PROXY refresh

        subscription-manager --proxy=$PROXY repos --help

        subscription-manager --proxy=$PROXY repos --list > list

        cat list | grep 'Repo ID' | grep -v source | grep -v debug

        subscription-manager --proxy=$PROXY repos --disable="*"

        subscription-manager --proxy=$PROXY repos \
            --enable="rhel-8-for-x86_64-baseos-beta-rpms" \
            --enable="rhel-8-for-x86_64-appstream-beta-rpms" \
            --enable="rhel-8-for-x86_64-supplementary-beta-rpms" \
            --enable="rhel-8-for-x86_64-rt-beta-rpms" \
            --enable="rhel-8-for-x86_64-highavailability-beta-rpms" \
            --enable="rhel-8-for-x86_64-nfv-beta-rpms" \
            --enable="fast-datapath-beta-for-rhel-8-x86_64-rpms" \
            --enable="codeready-builder-beta-for-rhel-8-x86_64-rpms" \
            # --enable="dirsrv-beta-for-rhel-8-x86_64-rpms" \
            # ansible-2.9-for-rhel-8-x86_64-rpms

        cat << EOF >> /etc/dnf/dnf.conf
        proxy=http://$PROXY
        EOF

        # 编译内核,需要rhel7, rhel8里面的epel的包

        yum -y install https://dl.fedoraproject.org/pub/epel/epel-release-latest-7.noarch.rpm
        dnf -y install https://dl.fedoraproject.org/pub/epel/epel-release-latest-8.noarch.rpm

        yum -y install yum-utils rpm-build

        yum list kernel.x86_64

        # 下载内核源码包

        yumdownloader --source kernel.x86_64

        # 安装源码包

        rpm -ivh /root/kernel-4.18.0-221.el8.src.rpm

        cd /root/rpmbuild/SPECS

        # https://stackoverflow.com/questions/13227162/automatically-install-build-dependencies-prior-to-building-an-rpm-package

        # 安装辅助包

        yum-builddep kernel.spec

        # 生成配置

        rpmbuild -bp --target=x86_64 kernel.spec

        # libbabeltrace-devel

        # https://www.cnblogs.com/luohaixian/p/9313863.html

        KERNELVERION=`uname -r | sed "s/.$(uname -m)//"`
        KERNELRV=$(uname -r)
        /bin/cp -f /root/rpmbuild/BUILD/kernel-${KERNELVERION}/linux-${KERNELRV}/configs/* /root/rpmbuild/SOURCES/

        cd /root/rpmbuild/BUILD/kernel-${KERNELVERION}/linux-${KERNELRV}/

        /bin/cp -f configs/kernel-4.18.0-`uname -m`.config .config

        # cp /boot/config-`uname -r`   .config

        make oldconfig

        # 自定义配置,请观看视频

        make menuconfig

        # vi .config

        # CONFIG_MLX5_TC_CT=y

        # CONFIG_NET_ACT_CT=m

        # CONFIG_SKB_EXTENSIONS=y

        # CONFIG_NET_TC_SKB_EXT=y

        # CONFIG_NF_FLOW_TABLE=m

        # CONFIG_NF_FLOW_TABLE_IPV4=m  x

        # CONFIG_NF_FLOW_TABLE_IPV6=m  x

        # CONFIG_NF_FLOW_TABLE_INET=m

        # CONFIG_NET_ACT_CONNMARK=m x

        # CONFIG_NET_ACT_IPT=m  x

        # CONFIG_NET_EMATCH_IPT=m   x

        # CONFIG_NET_ACT_IFE=m  x

        # 指明编译x86

        # x86_64

        sed -i '1s/^/# x86_64\n/' .config

        /bin/cp -f .config configs/kernel-4.18.0-`uname -m`.config
        /bin/cp -f .config configs/kernel-x86_64.config

        /bin/cp -f configs/* /root/rpmbuild/SOURCES/

        cd /root/rpmbuild/SPECS

        # cp kernel.spec kernel.spec.orig

        # https://fedoraproject.org/wiki/Building_a_custom_kernel

        # 自定义内核名称

        sed -i "s/# define buildid \\.local/%define buildid \\.wzh/" kernel.spec

        # rpmbuild -bb --target=`uname -m` --without kabichk  kernel.spec 2> build-err.log | tee build-out.log

        # rpmbuild -bb --target=`uname -m` --without debug --without debuginfo --without kabichk kernel.spec 2> build-err.log | tee build-out.log

        rpmbuild -bb --target=`uname -m` --with baseonly --without debug --without debuginfo --without kabichk kernel.spec 2> build-err.log | tee build-out.log

        cd /root/rpmbuild/RPMS/x86_64/

        # 安装编译的内核

        INSTALLKV=4.18.0-221.el8.wzh

        yum install ./kernel-$INSTALLKV.x86_64.rpm ./kernel-core-$INSTALLKV.x86_64.rpm ./kernel-modules-$INSTALLKV.x86_64.rpm

        # 重启以后,检查内核模块激活

        grep -R --include=Makefile CONFIG_NET_ACT_IFE

        # rpmbuild/BUILD/kernel-4.18.0-221.el8/linux-4.18.0-221.el8.wzh.x86_64/net/sched/Makefile:obj-$(CONFIG_NET_ACT_IFE) += act_ife.o

        modprobe act_ife
        lsmod | grep act_ife

本次实验编译完成的rhel kernel的包,在这里下载:

链接: https://pan.baidu.com/s/1AG07HxpXy9hoCLMq9qXi0Q 密码: 7hkt –来自百度网盘超级会员V3的分享
